ATEX Fixed Telephone

Le Las 410

The new TLA410E15A is an industrial analogue telephone in die-cast aluminum (6 mm thick), vandal-proof and impact-resistant IK10, with aluminum telephone handset, degree of protection IP66. The extremely robust stainless steel keyboard compartment is made up of aluminum keys Ø13 mm sufficiently spaced between them to be used with protective gloves.

Communication takes place through the handset.



Available In

  • Telephone
  • Intercom with handset
  • Hands-free
  • Hands-free 1 button

About Le Les

Since its inception in 1909, Le Las has set itself aim of solving problems of communications in the most difficult environments. The equipment of the fleet of the Navy to firedamp mines in the beginning, Le Las extended its experience and dynamism to the most varied environments, sea, rail transport, ports and airports, chemical plants, oil or simply urban, energy sectors, laboratories and hospitals, civil and military administrations, etc .

According to the certified ISO 9001 quality procedures, totally computerized design and manufacture services adapt the most recent technical inputs (like already GSM or voice over IP) in a full range. The development of electronic and mechanical modules allows us to offer a wide range of easily customizable products for the most reduced costs.

Electrical Characteristics Details
Line voltage 12 to 60 Vcc
Consumption 40mA
Voltage ringing 30 – 90 Vac ; 20-64Hz
Numbering DTMF / decimal
Audible Call Signal >85 dB / 1 m
Handset commutation Magnetic (also available in mechanical version)
Conversation mode Handset
Telephone handset cord Stainless steel resistance + 100 Kgs
Microphone Weatherproof electret type (adjustable volume)
Howler Weatherproof piezo type (adjustable volume)

Options:
Call Optical Flash
Another cover colors
Additionnal cable entry
Another types of cable glands
Hinge
Mechanical handset comutation: TLA410E15A/X15
