ATEX Fixed Telephone
Le Las 229 Series
Introducing the Le Las TLA 229 Polycarbonate ATEX Telephone, a state-of-the-art communication solution designed for hazardous environments. Certified to meet ATEX standards, this robust telephone ensures safe and reliable operation in explosive atmospheres, making it ideal for use in industries such as oil and gas, petrochemical, and mining. The TLA 229 features a durable polycarbonate housing, providing exceptional resistance to extreme weather conditions and mechanical impacts. Its advanced design guarantees clear communication, even in the harshest environments.
Available With Optional
- Hands-Free
- Digital Display
- Keyboard & Memory
- 1 Button
- Flashing Beacon
- Remote Diagnostics
Available Options
| Model | Handset | Hands-free | Keypad | Display | Flashlight | Single Call Button | Remote Control |
|---|---|---|---|---|---|---|---|
| TLC229A1 | ✔ | ✔ | |||||
| TLA229A1 | ✔ | ✔ | ✔ | ||||
| TLS229A1C9G | ✔ | ✔ | ✔ | ✔ | |||
| TLS229A1C9FGL | ✔ | ✔ | ✔ | ✔ | ✔ | ✔ | |
| TLS229A1C9FL | ✔ | ✔ | ✔ | ✔ | |||
| TLS229A1B | ✔ | ✔ | ✔ |
| Feature | Specification |
|---|---|
| Body Material / Color | Polyester plastic / RAL2003 (orange) |
| Handset Material / Color | Polyester plastic / black |
| Handset Cord | Stainless steel with 100 kg resistance |
| Loudspeaker (Hands-Free) / Microphone | Vandal resistant / 5W, 78 dB at 1 m |
| Mounting | On wall (2 or 4 fixing holes) |
| Termination | Inside screw connections |
| Dimensions | 201 x 320 x 113 mm |
| Weight | 2.4 kg |
| IP Rating | IP66 (protection against dust and powerful water jets) |
| Impact Rating (1K) | 10 |
| EEx Protection | EEx em [ib] ib IIC T5 / ATEX 11 2 G D |
| Max. / Min. Ambient Temperature | -40°C / +60°C |
| Maintenance | All circuits and control devices are fixed on the easily removable front plate for quick substitution of equipment in the field. |
