GM International D5000 Series
Intrinsically Safe Galvanic Isolators for Hazardous Area Signal Interfacing
D5000 Series I.S. Galvanic Isolators
The GM International D5000 Series is a modular range of intrinsically safe galvanic isolators used to safely interface hazardous area field devices with safe area control systems.
The range includes modules for 4–20 mA/HART transmitter loops, digital inputs, solenoid valve outputs, trip signals, temperature inputs, vibration interfaces and specialist signal conditioning applications.
For process automation, functional safety and hazardous area instrumentation projects, the D5000 Series provides a compact and flexible way to manage safe signal transfer.
Need help selecting the right module? Exloc can help identify the correct D5000 option and provide the relevant datasheets, certificates and quotation support.
Why choose the D5000 Series?
The D5000 Series is designed for hazardous area instrumentation systems where safety, signal reliability, cabinet space and ease of maintenance all matter.
Wide Module Range
The D5000 family includes analogue input, analogue output, digital input, digital output and specialist interface modules for a wide range of hazardous area signal applications.
High-Density Design
Many D5000 modules provide multiple channels in compact housings, helping reduce cabinet space in larger I.S. installations.
SIL 2 and SIL 3 Options
The range includes modules suitable for SIL 2 and SIL 3 applications, depending on the specific model and system design.
HART-Compatible Modules
Selected analogue input and output modules support HART communication for smart transmitter, valve positioner and asset management applications.
Line Fault Detection
Selected modules can detect open-circuit and short-circuit field wiring faults, helping maintenance teams identify loop issues more quickly.
Flexible Mounting
D5000 modules can be installed on DIN rail, with power bus options or on termination boards for larger project and cabinet integration requirements.
Analogue Input Modules
D5011S - 1 channel SIL 3 Repeater Power Supply Hart, D5011S Datasheet
D5011D - 2 channel SIL 3 Repeater Power Supply Hart, D5011D Datasheet
D5014S - 1 channel SIL 3 Repeater Power Supply Hart, D5014S Datasheet
D5014D - 2 channel SIL 3 Repeater Power Supply Hart, D5014D Datasheet
D5016DK - 2 Channel I.S. SIL3 2-Wire Acitve HART Tx Current Repeater (Sink Output) D5016DK Datasheet
D5016DS - 2 Channel I.S. SIL3 2-Wire Acitve HART Tx Current Repeater (Source Output) D5016DS Datasheet
D5016SK - 1 Channel I.S. SIL3 2-Wire Acitve HART Tx Current Repeater (Sink Output) D5016SK Datasheet
D5016SS - 1 Channel I.S. SIL3 2-Wire Acitve HART Tx Current Repeater (Source Output) D5016SS Datasheet
D5212Q - 4 Channel SIL2 Repeater Power Supply (Modbus) D5212Q Data Sheet
Analogue Output Modules
D5020S - 1 channel SIL 3 Powered Isolating Driver Hart, D5020S Datasheet
D5020D - 2 channel SIL 3 Powered Isolating Driver Hart, D5020D Datasheet
Digital Input Modules
D5030S - 1 channel, SIL 3 Switch/Proximity Repeater, Relay Output D5030S Datasheet
D5030D - 2 channel, SIL 3 Switch/Proximity Repeater, Relay Output D5030D Datasheet
D5031S - 1 channel, SIL 3 Switch/Proximity Detector Transistor Out, D5031S Datasheet
D5031D - 2 channel, SIL 3 Switch/Proximity Repeater Transistor Out, D5031D Datasheet
D5032S - 1 channel, SIL 3 Switch/Proximity Repeater Relay Output (Termination board only) D5032S Datasheet
D5032D - 2 channel, SIL 3 Switch/Proximity Repeater Relay Output (Termination board only) D5032D Datasheet
D5034S - 1 channel, SIL 3 Switch/Proximity Interface, D5034S Datasheet
D5034D - 2 channel, SIL 3 Switch/Proximity Interface, D5034D Datasheet
D5036S - 1 channel, SIL 2 Switch/Proximity Interface - D5036S Datasheet
D5036D - 2 channel, SIL 2 Switch/Proximity Interface - D5036D Datasheet
D5037S - 1 channel, SIL 2 Switch/Proximity Interface - D5037S Datasheet
D5037D - 2 channel, SIL 2 Switch/Proximity Interface - D5037D Datasheet
D5233Q - I.S. SIL2 Switch/Proximity Transistor-Out Repeater - D5233Q Datasheet
D5232Q - I.S. SIL2 Switch/Proximity Relay-Out Repeater - D5232Q Datasheet
D5231E - 8 channel, SIL 2 Switch/Proximity Detector Repeater, O.C. Output D5231E Datasheet
Digital Output Modules
D5040S - 1 channel, SIL3 Digital Output Driver, D5040S Datasheet
D5040D - 2 channel, SIL3 Digital Output Driver, D5040D Datasheet
D5240T - 3 channel, SIL3 Digital Output Driver, D5240T Datasheet
D5048S - 1 channel, SIL 3 Digital Output Driver, D5048S Datasheet
D5049S - 1 channel, SIL 3 Digital Output Driver, D5049S Datasheet
D5244S - 1 Channel, SIL 3 Digital Relay Output, Loop Powered D5244S Datasheet
D5244D - 2 Channel, SIL 3 Digital Relay Output, Loop Powered D5244D Datasheet
PSD5201 - 1 Channel, SIL 3 Digital Output Driver PSD5201 Datasheet
Frequency Convertor / Trip Amp Modules
D5060S - Prox I/P - Analogue & Trip O/P - Coming Soon
Load Cell / Strain Gauge Input Modules
D5263S - Transparent Repeater - D5263S Datasheet
D5264S - Analogue and Modbus O/P - D5264S Datasheet
Temperature Input Modules
D5072S – 1 Ch. SIL 2 Temperature Signal Converter, Multifunction D5072S Datasheet
D5072D – 2 Ch; SIL 2 Temperature Signal Converter, Multifunction D5072D Datasheet
D5072S-087 - 1 Ch; RTD/Resistance Isolating Repeater D5072S-087 Datasheet
D5072D-087 - 2 Ch; RTD/Resistance Isolating Repeater D5072D-087 Datasheet
D5072S-096 - 1 Ch; Thermocouple Isolating Repeater D5072S-096 Datasheet
D5072D-096 - 2 Ch; Thermocouple Isolating Repeater D5072D-096 Datasheet
D5273S - SIL 2 Temperature Signal Converter, Multifunction, Trip Amplifiers D5273S Datasheet
D5274S - I.S. SIL2 Temp. Trip Amplifier with Zero/Span Trimmers D5274S Data sheet
Power Bus System Distribution & Diagnostic Modules
D5202S - SIL 3, 4 A, 24 Vdc Power Distribution and Diagnostic Module D5202S Datasheet
D5203S - Common Alarm Module (SPDT) for D5000/D6000 Series D5203S Datasheet
Termination Board Mounting
- Mount up to 8 or 16 modules for up to 64 I/O channels
- Dual redundant 24VDC power connections with fuses
- Multipin connector for safe area connections
- HART multiplexer connections
- Common fault output terminals
- Optional design accommodates two relay modules to provide separate relay contacts for power and I/O line fault indication
- Termination boards can be DIN rail or panel mounted
- Custom Termination Boards (Honeywell, Trinconex, ABB, Invensys, Yokogawa, Emerson, Hima, Schneider, Siemens, Bailey)
Isolator Enclosure
ENC-001
Our standard unit is a GRP isolator enclosure with clear lid. Fitted with Din Rail and with M20 knockouts.
We are happy to quote for options of larger and smaller versions of these enclosures and to provide quotes for systems fitted with modules and glands etc. For further information please contact us.
SWC5090 Configuration Software for D5000 and D5200 Isolators
- Configurable D5000/D5200 Isolators can be fully managed with this easy to use application.
Ex Loop Safety Parameters Verification
-
- This easy to use online web application allows the user to verify IS loops according to the latest standards.
- Contains all updated data on GM Products.
