IS945.2

ATEX Zone 2 / 22 Windows Tablet

IS945.2

5G Windows Tablet for ATEX Zone 2/22

The IS945.2 is a rugged 10.1-inch Windows tablet designed for safe and reliable data communication in ATEX and IECEx Zone 2/22 hazardous areas. Running Windows 11 IoT Enterprise LTSC for Arm64, it enables industrial teams to access familiar Windows applications, documentation and digital workflows directly in the field.

Powered by a Qualcomm® QCM6490 octa-core processor with 8 GB of RAM, the IS945.2 delivers responsive performance for inspections, maintenance activities, reporting and other industrial applications. It also includes 128 GB of internal storage, with support for additional storage using a microSD card.

The large 10.1-inch display features Corning® Gorilla® Glass and can be operated while wearing gloves. Integrated 5G, Wi-Fi 6, Bluetooth® 5.2 and satellite positioning provide flexible connectivity across industrial sites, while front and rear cameras support documentation, remote assistance and video communication.

An 8160 mAh field-replaceable battery helps reduce downtime during extended working periods. The IS945.2 is also IP68-rated, tested to MIL-STD-810H and suitable for use in temperatures from -20°C to +55°C, providing dependable operation in challenging industrial environments.

Combining Windows functionality, robust construction and hazardous-area certification, the IS945.2 is a strong choice for organisations that need secure access to digital systems and Windows-based workflows in Zone 2/22 environments.





Key Features

  • Certified for ATEX and IECEx Zone 2/22 hazardous areas

  • High-performance octa-core processor with 8GB RAM

  • Windows® 11 IoT Enterprise for Arm64

  • Integrated 5G, Wi-Fi, Bluetooth, and GPS

  • Large 10.1-inch sunlight-readable touchscreen

  • Long-lasting, field-replaceable battery

  • Ultra-rugged design for industrial environments

  • Optimised for oil and gas, chemical, and manufacturing industries

Windows® 11 IoT Enterprise for Arm64

5G Connectivity

Replaceable Powerful Battery

Full-HD 10.1"  Display

Amplified Loudspeaker

Accelerometer, Gyroscope, Light, Magnetic, Proximity, Pressure Sensors

Dual-SIM (Nano-SIM + eSIM)

USB-C, Docking Station

Accessories

IS-MC930.1 Multi Charger Set

Multi Charger for six devices. Size: 600 x 250 x 115 mm (L x W x H). Compatible for IS930.x, IS940.x, IS945.x and IS910.x.

IS-HDHS1B.1 Headset Set (Neckband)

Comfortable, noise-insulating headset with outstanding features such as a pleasant wearing comfort thanks to the soft ear pads, first-class audio components, approx. 27 dB sound attenuation and a microphone with excellent noise cancellation. The robust design is also suitable for difficult environments and the textile headband allows helmets and bump caps to be worn.

IS-HDHS1C.1 Headset Set (Helm Mount)

Comfortable, noise-insulating headset with outstanding features such as a comfortable fit thanks to the soft ear pads, first-class audio components, approx. 27 dB sound attenuation and a microphone with excellent noise cancellation. The helmet attachment can be selected depending on the helmet type.

IS-PTTB1A.1 PTT Button Set (16-pin)

The housing of the PTT button is made of impact-resistant, fibreglass-reinforced plastic and is ideally suited for robust use. Thanks to the splash water protection, it can also be used in a damp environment or in daily use in outdoor areas without any worries. There is a fastening clip on the back for attachment. The large, fluorescent transmit button allows safe operation even in hectic situations and the additional mountable protective ring prevents the button from being pressed accidentally.

Leather Case black IS940.x/IS945.x

Made of high quality leather, black. With adjustable Shoulder Strap and holder for a stylus. Suitable for the devices IS940.x and IS945.x.

Leather Case yellow IS940.x/IS945.x

Made of high quality leather, yellow. With adjustable neck strap and holder for a stylus. Suitable for the devices IS940.x and IS945.x.

Shoulder Strap 30 mm for Leather Case tablet

Made of durable blended fabric, adjustable.

4-point Harness System tablet

The carrying strap system, made of Teflon impregnated Cordura®, is designed for use with the new Leather Cases of the IS910.x, IS930.x & IS940.x devices. It ensures safe carrying in front of the body and consists of an ergonomic back harness with extra large contact areas on the shoulders. The strap adjustment options allow the working height and angle of inclination to be adjusted as required.

Vehicle mount IS930.x/IS910.x/IS94x.x

The extremely stable and robust vehicle mount for the tablets of the IS940.x, IS945.x, IS930.x and IS910.x series designed for the rough industrial use „heavy duty". With the two connecting arms of different lengths, it can be adapted to the different vehicle interiors.

IS-Stylus Set

Stylus for operating touch screens. Made of metal with exchangeable rubber tip and plastic spiral cable. Stylus dimensions: 125 x 10 mm (L x ø); length of spiral cable: flexible from 24 to 70 cm.

PanzerGlass™ IS940.x/IS945.x

PanzerGlass® foil for an extended protection of the display. Suitable for the devices IS940.x and IS45.x.

Warranty extension

With our comprehensive warranty and service offer, you can protect yourself against additional service costs and receive years of safety and protection directly from the manufacturer. From the very first day, your equipment is protected against accidental damage and normal wear and tear. This reduces your total cost of ownership and benefit from the precision and functionality of our equipment for a long time.
Learn More

Certificates

ATEX Certification

II 3G Ex ic IIC T4 Gc
II 3D Ex ic IIIC T135°C Dc



IECEx Certification

Ex ic IIC T4 Gc
Ex ic IIIC T135°C Dc



Technical features

Operating system Windows® 11 IoT Enterprise for Arm64
Processor Qualcomm® QCM6490 Octa Core
Memory 8 GB RAM
128 GB internal memory
microSD card supported
Frequencies 4G LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B12 MFBI/B13/B14/B17/B20/B25/B26/B28A/B28B/B29/B30/B66/B68/B71
4G LTE-TDD: B38/B39/B40/B41/B42/B43/B48
5G NR: n1/n2/n3/n5/n7/n8/n12/n14/n20/n25/n28/n30/n38/n40/n41/n48/n66/n71/n77/n78/n79
Dimensions Size: 266,17 x 168,46 x 19,82 mm
Weight: 1059 g
Display 10,1" (25,654 cm) Corning® Gorilla® Glass V3
usable with gloves
Battery 8160 mAh, 3,7 V
replaceable
Camera 12 MP AF rear
5 MP FF front
Connectivity Wi-Fi® 6: IEEE 802.11 a/b/g/n/ac/e/k/r/ax/v with hotspot
Bluetooth® 5.2
GPS, A-GPS, Glonass, Beidou, Galileo
Types of protection IP68 dust-/waterproof
MIL-STD 810H
Usable from -20 °C to +55 °C
Interfaces USB-C
ISM interface
12-pin docking interface

INCLUDED

  • Tablet
  • Battery
  • i.safe PROTECTOR 2.0
  • Power Adapter universal
  • Display Protection Foil
  • Screwdriver
  • Quick Start Manual
  • Safety Instructions

Datasheet

ATEX Certificate

IECEx Certificate
